Airbrush mini compressor with air reservoir Fengda AS-189 (FD-189)
  • Item number: FD-AS189
109,75 €

including 16% VAT., no shipping costs to: DE , shipping (Standard)

Recommended retail price: 109,75 €
Available now!

Shipping time: 2-4 Days*

Shipping takes place every day at 12 noon


Airbrush mini compressor with air reservoir Fengda AS-189 (FD-189)

Airbrush compressor with compressed air tank - Fengda AS-189 (FD-189)

Powerful, light and portable airbrush compressor with 3 L compressed air tank, for beginners and professionals! Very quiet with only approx. 47 dB. It works fully automatically and largely pulsation-free, is oil-free and therefore does not produce polluted air. Equipped with pressure reducer (incl. Oil and water filter and pressure gauge). Perfect work due to constant working pressure (regulator + compressed air tank). The unit of this compressor is identical to the AS-18-2 (FD-18-2), only that this compressor has a compressed air tank. In contrast to the AS-186 (FD-186), this type of compressor has two freely selectable operating states. Level 1 is an auto ON / OFF mode (automatic start / stop). The unit starts automatically at 2.8 bar pressure in the compressed air tank and stops automatically when 4 bar pressure is reached in the compressed air tank. Level 2 is a continuous running mode in which the unit works continuously and delivers air. When the max. Working pressure in the compressed air tank of 6 bar, opens the safety valve and blows off the excess pressure. This mode is for larger airbrush jobs such as Suitable for off-road construction or priming several vehicles and should not be operated for longer than 15 minutes! This control offers several advantages: - Individual use of the compressor depending on requirements - Uniform air volume flow for the user - Protection of the unit (extension of the service life) - Low volume during operation, so that the compressor can also be used at home in the evening - Overheating of the unit is largely taken care of Low volume in operation, can also be used at home in the evening. Thanks to its low weight, it is portable and suitable for home and hobby use (model making). Can be used for airbrush guns with nozzles from 0.15 - 0.4 mm.

Scope of delivery:

1x compressor with 3 L compressed air tank 1x pressure reducer, with filter and pressure gauge 1x power cable (Schuko) 1x instructions (English)

Area of ??application

Can be used for airbrush guns with nozzles from 0.15 - 0.4 mm. This compressor is particularly suitable for use in the tabletop and model building hobby. Suitable for painting large models and single miniatures. Other areas of application: Suitable for airbrushes and can be used in model making, handicrafts, ceramics, pottery, cosmetics, fingernails, helmets, technical illustrations, tanning, tattoo, textiles, nail art studios, tattoo, working with water colors, body colors, hobbies, model toys , Fingernail design. It can also be used as an air source in medical applications, environmental protection, aquariums, food and chemical industries, laboratories, etc.

Technical data:

- Compressed air tank with 3 L volume - Adjustable working pressure: 0 bar to 6 bar - Expression: 20 - 23 L / min without load - Pressure range of the pressure reducer: 0 - 10 bar (0-150 PSI) - Safety / drain valve - Air connection thread (compressed air): G 1/8 "AG (9.51 mm) - Thermal protection (overheating protection) - Two-stage on / off switch

Switch level 1 = Auto-ON / OFF or automatic start / stop (automatic start-up: from approx. 3 bar boiler pressure (43PSI), automatic switch-off: from 4 bar boiler pressure (57PSI))

Switch level 2 = continuous running at max. Working pressure (6 bar, safety valve automatically blows off above 6 bar)

- Power cable length: 1.9m - Voltage: 220-240 V / 50 Hz - Power: 0.123 kW (1/6 HP) - Speed: 1450/1700 r.p.m. - Volume: 47 dB / 1m (very quiet) - Weight: 4.8 kg (light and portable) - Dimensions: 32 x 14 x 31 cm / 12.6 x 5.5 x 12.2in - 4 non-slip rubber feet - Certificates: CE, GS, ETL, CETL, ROHS
short information
  • Item number:
    FD-AS189
  • Category:
  • Shipping weight:
    5,90 Kg
  • Product weight:
    4,50 Kg
